Industralight IL6063 LED Landscape Bollard

Industralight IL6063 LED is a high-quality LED bollard fixture for landscape lighting applications. The fitting is constructed from quality materials and incorporates new generation LED light source with advanced efficiency and optical performance. IL6063 is available in different colour finishes, and is suited for any commercial or residential application.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption10W
LED Driver ClassificationIntegral Constant Current
Light Source ClassificationHigh Power COB LED

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP64
Profile Dimensions120x50mm
Overall Height800mm
Construction MaterialExtruded Aluminium
Standard Colour/FinishCorrosion Resistant
Recommended Operating Temp  -15°C – 45°C

Configuration Options

  • Non standard colours available by special request
  • Integral DALI dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy75lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Indec [CRI]>80
Beam Angle/Viewing Angle110°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberIL6063
Specify Colour Temp3000K / 4000K / 6500K
Specify Fixture ColourDark Charcoal / Opal Grey
Specify Wattage10W
Warranty InformationExtended Warranty Available
