IL6063 LED Landscape Bollard
Industralight IL6063 LED is a high-quality LED bollard fixture for landscape lighting applications. The fitting is constructed from quality materials and incorporates new generation LED light source with advanced efficiency and optical performance. IL6063 is available in different colour finishes, and is suited for any commercial or residential application.
Electrical Parameters
| Input Voltage | 100-240VAC |
| Max Power Consumption | 10W |
| LED Driver Classification | Integral Constant Current |
| Light Source Classification | High Power COB LED |
Mechanical Specifications
| Minimum IK Rating | IK09 |
| IP Protection Rating | IP64 |
| Profile Dimensions | 120x50mm |
| Overall Height | 800mm |
| Construction Material | Extruded Aluminium |
| Standard Colour/Finish | Corrosion Resistant |
| Recommended Operating Temp | -15°C – 45°C |
Configuration Options
- Non standard colours available by special request
- Integral DALI dimmable LED driver available by special request
Photometric Information
| Typical Light Source Efficacy | 100lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Indec [CRI] | >80 |
| Beam Angle/Viewing Angle | 110° |
Detailed photometric report and IES files available by request
