Industralight IGR9230 Inground LED Uplight

Industralight IGR9230 is a commercial grade inground luminaire with integrated LED light source and advanced optical configuration. The luminaire is constructed from marine grade stainless steel and toughened tempered glass lens. Available with single colour or RGB LED light source. IGR9230 is supplied with PVC mounting housing.

Electrical Parameters

Input Voltage24VDC
Max Power Consumption30W
LED Driver ClassificationConstant Voltage
Light Source ClassificationCREE CXA1816

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP67
Overall Trim Diameter250mm
Fitting Depth65mm
Overall Depth in Housing126mm
Construction Material316 Stainless Steel
Recommended Operating Temp-20°C – 50°C

Configuration Options

  • Trim can be powdercoated by special request
  • RGB / RGBW Configuration available by request
  • Remote mounted DALI dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4000K / 5000K / RGB / RGBW
RGB Control Range0-100% 256-bit
Colour Rendering Indec [CRI]>80
Beam Angle/Viewing Angle15° / 24° / 38° / 100°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberIGR9230
Specify Colour Temp3000K / 4000K / 5000K
Optional RGB(W) ConfigurationRGB / DMX512 / PWM Controller
Beam Angle15° / 24° / 38° / 100°
Included AccessoryInground Mounting Housing
Warranty InformationExtended Warranty Available
