IGR901 Inground LED Pathway Light
Industralight IGR901 is a stylish inground fixture for exterior pathway and driveway lighting. IGR901 is manufactured from stainless steel with specular internal reflector and tempered glass lens. The integrated LED light source provides efficient lumen output with minimal light spill. Suitable for commercial or residential projects.
Electrical Parameters
| Input Voltage | 100-240VAC / 24VDC |
| Max Power Consumption | 3W |
| LED Driver Classification | Integral LED Driver |
| Light Source Classification | Epistar SMD |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP67 |
| Overall Diameter | 160mm |
| Overall Mounting Depth | 119mm |
| Construction Material | 316 Stainless Steel |
| Mounting Accessory | PVC Mounting Housing |
| Recommended Operating Temp | -20°C – 50°C |
Configuration Options
- 24VDC version available by request
- Remote mounted DALI dimmable LED driver available by special request
Photometric Information
| Typical Light Source Efficacy | 90lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Indec [CRI] | >85 |
| Beam Angle/Viewing Angle | 110° |
Detailed photometric report and IES files available by request
