Industralight IGR 293mm LED Inground Uplight

Industralight IGR LED Inground uplights are suitable for high-end commercial projects that require a high quality inground mounted uplight. The fittings are IP67 rated and are finished with high-grade stainless steel trim with tempered glass lens. LED driver and control gear is integral.

Electrical Parameters

Input Voltage:100-240VAC
Power Consumption:9.6W / 26W
LED Driver Classification:Integral Constant Current
Light Source Classification:CXA-LED(26W) XP-E Power-LED(9.6W)

Mechanical Specifications

Minimum IK Rating:IK08
IP Protection Rating:IP67
Nominal Diameter:293mm
Glass Lens Type:Clear 75°  or Soft-Frosted 120°
Material/Construction:Marine Grade Stainless Steel Trim
Recommended Ambient Temp:-20°C – 45°C

Configuration Options

  • PVC concrete mounting can available by request
  • Optional PVC terminal junction box
  • Clear or soft-frosted glass lens
  • 24VDC version available by special request
  • Non-standard colour finishes available by special request

Photometric Information

Typical Lumen Efficacy:85-90lm/W
CCT Colour Temperatures:3200K/4200K/6500K
Colour Rendering Index (CRI):>85
Viewing Angle:Clear 75° / Frosted 120°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details.

Series Model Number:IGR6078(26W) / IGR6079(9.6W)
Specify Colour Temp:3000K/4000K
PVC Mounting Can:IGR502-PVC
Specify Configuration:Clear 26W 75° or Frosted 9.6W 120°
Optional Anti Glare LouvreIGR501-LOUVRE (factory-fitted by request)
