Industralight ALT664 Inground LED Uplight

Industralight ALT664 is a commercial grade inground uplight luminaire with integrated LED light source and LED driver. The luminaire is constructed from marine grade stainless steel and toughened tempered glass lens. ALT664 features a specular aluminium reflector which delivers asymmetrical light distribution. Supplied with PVC mounting housing.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption42W
LED Driver ClassificationIntegral LED Driver
Light Source ClassificationCOB LED

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP67
Trim Dimensions170x270mm
Overall Mounting Depth230mm
Construction Material316 Stainless Steel
Recommended Operating Temp  -20°C – 50°C

Configuration Options

  • Trim can be powdercoated by special request
  • Integral DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4000K / 5000K
Colour Rendering Indec [CRI]>80
Beam Angle/Viewing AngleAsymmetrical

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberALT664
Specify Colour Temp3000K / 4000K / 5000K
Specify Wattage42W
Trim FinishStainless Steel
Included AccessoryInground Mounting Housing
Warranty InformationExtended Warranty Available
