GWU100 IP65 LED WALL LUMINAIRE

GWU100 is a high-quality LED luminaire, constructed from extruded aluminium with corrosion resistant powdercoated surface. GWU100 is suited to commercial and domestic projects where a high quality product is required. GW501 accepts a replaceable GU10 LED lamp which is available separately.

Electrical Parameters

Input Voltage: 100-240VAC
Power Consumption: Max 10W LED (GU10 Lamp)
LED Driver Classification: LED Logic, Constant Current
Lamp Configuration: 100-240VAC GU10 LED Lamp

Mechanical Specifications

Minimum IK Rating: IK09
IP Protection Rating: IP65
Overall Height: 110mm
Body Diameter: 110mm
Overall Projection From Wall: 90mm
Construction Material: Aluminium with Glass Visor
Standard Colour/Finish: Black / White / Silver / Custom
Recommended Ambient Temp: -15°C – 55°C

Configuration Options

  • Non standard colours available by special request
  • Dimmable / Non Dimmable GU10 LED lamp Options

Photometric Information

Typical Lumen Efficacy: 65-110lm/W
CCT Colour Temperature: 2700-6500K
Colour Rendering Index (CRI): 75-95Ra
Beam Angle/Viewing Angle: 10° / 30° / 60°

Control Options

GWU100 accepts industry standard GU10 LED lamp modules. This product can be customised or configured according to the needs of your project. Dimming and control options are lamp dependant and are available by special request.
