IL9210 Aero Max LED Washer

Industralight Aero-Max fitting is a high powered LED washer fitting ideally suited to large-scale highlighting of buildings, façade lighting and features, commercial wall grazing, and other exterior or interior lighting applications. The Aero-Max is avail­able in either 500mm or 1000mm nominal lengths and has built in LED control gear. Single colour and RGB+DMX colour control versions are available.

Electrical Parameters

Input Voltage 100-240VAC
Max Power Consumption 36W / 72W
LED Driver Classification Integral Constant Current
Light Source Classification CREE XPE
Optional RGB Configuration RGB + Built-In DMX512

Mechanical Specifications

Minimum IK Rating IK09
IP Protection Rating IP65
Profile Dimension 100x100mm
Fixture Lengths 500mm / 1000mm
Standard Colours/Finish Graphite
Recommended Operating Temp -20°C – 50°C

Configuration Options

  • Non standard colours available by special request
  • DALI or DMX dimmable LED driver available by request
  • Custom lengths available by special request

Photometric Information

Typical Light Source Efficacy 90lm/W
CCT Colour Temperatures 3000K / 4000K / 6000K / RGB
Beam Angle/Viewing Angle 36° x 60°
RGB Option 16.7mill Colour Mix Output

Detailed photometric report and IES files available by request
