FL7100 LED Floodlight
Industralight FL7 is a new generation LED floodlight with integrated mains voltage LED module. FL7 delivers superior lumen output with optimum efficiency. The fittings are manufactured from robust materials and can be used in any Industrial, commercial or residential environment.
Electrical Parameters
Input Voltage | 85-285VAC |
Power Options | 100W / 120W |
LED Driver Classification | Class 1 |
Light Source Classification | Osram 3030T |
Mechanical Specifications
Minimum IK Rating | IK09 |
IP Protection Rating | IP65 |
Nominal Dimensions | 270x250x130mm |
Construction Material | Aluminium |
Standard Colours/Finish | Black / Corrosion Resistant |
Recommended Operating Temp | -20°C – 50°C |
Configuration Options
- Also available in 120W configuration
- Non standard colours available by special request
- DALI dimmable version available by special request
Photometric Information
Typical Light Source Efficacy | 100lm/W |
CCT Colour Temperatures | 3000K / 4000K / 5000K / 6500K |
Colour Rendering Index [CRI] | >80 |
Beam Angle/Viewing Angle | 120° |
Detailed photometric report and IES files available by request
