CP800 SURFACE MOUNT LED CANOPY LUMINAIRE
CP800 is an industrial grade ceiling canopy luminaire that is suitable for general area lighting. The architecturally styled fittings are constructed die cast alloy body with polycarbonate and glass lens visor. CP800 features a powerful and efficient modular LED light source and integral LED driver. DALI or 1-10V control is optional.
ELECTRICAL PARAMETERS
| Input Voltage: | 90-277VAC |
| Power Consumption: | 75W / 110W / 150W |
| LED Driver Classification: | Meanwell |
| Light Source Classification: | Lumileds S3030 Modular |
MECHANICAL SPECIFICATIONS
| Minimum IK Rating: | IK09 |
| IP Protection Rating: | IP65 |
| Dimensions: | 420x420x140mm |
| Construction Material: | Die Cast Aluminium Alloy |
| Standard Colour/Finish: | Powdercoated White |
| Recommended Ambient Temp: | -40˚C – 50˚C |
| Nominal Net Weight: | 7.8KG |
CONFIGURATION OPTIONS
● Recessed versions available
● Non standard colours available by special request
● DALI dimmable LED driver available by request
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | 145lm/W |
| CCT Colour Temperature: | 3000K / 4000K / 6500K |
| Colour Rendering (Ra): | >80Ra (>90Ra Optional) |
| Beam Angle Options: | 90˚ x 60˚ / 120˚ |
CONTROL OPTIONS
This product can be customised or configured according to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
COMPLIANCE & CERTIFICATION
● IESNA2002
● AS/NZS60598, LM79, LM80
● Lifespan: Exceeds 50,000hrs @ L70
ORDERING INFORMATION
| Model Number: | CP800 |
| Specify LED CCT: | 3000K / 4000K / 5000K / 6500K |
| Specify Beam Angle: | 120˚ / 90˚x60˚ |
| Specify Wattage: | 75W / 110W / 150W |
| Input Voltage Option: | 90-277VAC / 24VDC |
| Dimming Option: | Non Dimmable / DALI / 1-10V / Sensor |
