Industralight BTU100 Industrial Linear LED Luminaire

Industralight BTU100 is a high-powered LED luminaire designed for industrial projects. BTU100 is constructed from corrosion resistant alloy with polycarbonate. The product is available in several configurations and wattage options. BTU100 is especially suited to manufacturing plants, product facilities, mining & industrial, warehouses, other industrial lighting projects.

Electrical Parameters

Input Voltage100-277VAC
Max Power Consumption120W / 180W / 240W
LED Driver ClassificationMeanwell CLG/HLG
Light Source ClassificationPhilips 3030

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP65
Nominal Lenghts590mm / 880mm / 1170mm
Profile Dimensions130x125mm
Construction MaterialExtruded Aluminium & Polycarbonate
Recommended Operating Temp-30°C – 55°C

Configuration Options

  • Custom modular sizes up to 600W available by request
  • 1/10V / DALI dimmable LED driver options available by request

Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Index [CRI]>85
Beam Angle/Viewing Angle30° / 60° / 90° / 30°x70°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberBTU100
Specify Colour Temp3000K / 4000K / 6500K
Standard Fixture Length590mm / 880mm / 1170mm
Specify Wattage120W / 180W / 240W
Warranty InformationExtended Warranty Available
