Industralight TL700 Tubeline Linear LED Fixture
Industralight TL700 Tubeline is a compact linear LED product that features high efficiency LED light source fitted inside a slim round polycarbonate housing. The round profile allows for the product to be orientated at a varying angles which makes the product ideal for display cases, freezer units, retail and counter displays, other concealed lighting applications.
Electrical Parameters
| Input Voltage | 24VDC |
| Max Power Consumption | 6.5W / 12W / 14.5W |
| LED Driver Classification | Constant Voltage |
| Power Connection | 2.5mm DC Plug |
| Light Source Classification | SMD2835 |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP54 |
| Nominal Lengths | 600mm / 1200mm / 1500mm |
| Construction Material | Toughened Polycarbonate |
| Fixing Method | Round Mounting Clip |
| Recommended Operating Temp | -25°C – 60°C |
Configuration Options
- 900mm length available by request
- Other non standard lengths available by special request
- Dimmable LED driver configurations by request
Photometric Information
| Typical Light Source Efficacy | 90lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >85 |
| Beam Angle / Viewing Angle | 120° |
Detailed photometric report and IES files available by request
Lighting Design & Simulations
Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.
Warranty Information
Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.
Please see our warranty policy for full details
