Industralight ALT2210T Inground LED Uplight

Industralight ALT2210T is a high quality inground uplight luminaire which is designed for commercial and residential lighting projects. The fitting features a 316 marine grade stainless steel construction with tempered glass lens. ALT2210T also incorporates a unique tilt internal body, allowing the illumination to be focused and adjusted as required.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption10W
LED Driver ClassificationIntegral, Constant Current
Light Source ClassificationCitizen COB

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP67
Overall Trim Diameter148mm
Body/Housing Diameter140mm
Overall Depth130mm
Construction Material316 Stainless Steel
Fitting Tilt Adjustable15° Centre-Tilt Adjust
Recommended Operating Temp-10°C – 55°C

Configuration Options

  • Low Glare Baffle Louvre Accessory available
  • PVC Plastic Mounting Housing included
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy85lm/W
CCT Colour Temperatures3000K / 4000K / 5000K
Colour Rendering Indec [CRI]>85
Beam Angle/Viewing Angle10°/30°
Fitting Tilt Adjustable15° Centre-Tilt Adjust

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberALT2210T
Specify Colour Temp3000K / 4000K / 5000K
Mounting HousingPVC Mounting Housing Included
Specify Beam Angle10° / 30°
Optional AccessoryLow Glare Baffle Available
Warranty InformationExtended Warranty Available
