WPL362S LED WALL PACK/BULKHEAD
WPL362S is a IK10 toughened product, surface mounted wall luminaire suited to general lighting applications and security This ruggedly designed fitting efficiently diffuses the high output LED light source through an optical semi-prismatic polycarbonate front lens. Can be fitted with PE sensor or motion sensor.
Electrical Parameters
| Input Voltage: | 120-277VAC |
| Power Consumption: | 18W |
| LED Driver Classification: | Integral, Constant Current |
| Light Source Classification: | Epistar SMD LED |
Mechanical Specifications
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP65 |
| Nominal Dimensions: | 136x215x87mm |
| Construction Material: | Toughened Polycarbonate |
| Standard Colour/Finish: | Black / White / Silver |
| Recommended Ambient Temp: | -20 ̊C – 45 ̊C |
Configuration Options
- Available in ceiling-mount or wall-mount options
- Optional photoelectric dawn/dusk sensor (PE Cell)
Photometric Information
| Typical Lumen Efficacy: | 100lm/W |
| CCT Colour Temperature: | 3000K/4000K/6500K |
| Colour Rendering (Ra): | >85Ra |
| Beam Angle/Viewing Angle: | 120° |
Control Options
This product can be customised or configured according to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
