WPK630 LED Wall Pack Luminaire
Industralight WPK630 is a professional wall mounted luminaire for commercial and industrial projects. The body is manufactured from toughened materials with vandal resistant polycarbonate visor. WPK630 is ideal for general purpose lighting in courtyards, common areas, carparks, security lighting, commercial sites.
Electrical Parameters
| Input Voltage | 100-277VAC |
| Max Power Consumption | 50W / 70W / 100W |
| LED Driver Classification | Integral High Efficiency |
| Light Source Classification | Lumileds |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP65 |
| Nominal Dimensions | 264x308mm |
| Overall Depth From Wall | 182mm |
| Construction Material | Aluminium & Polycarbonate |
| Standard Colour/Finish | Black |
| Recommended Operating Temp | -30°C – 45°C |
Configuration Options
- Optional 200-480VAC version by special request
- DALI dimmable LED driver available by special request
Photometric Information
| Typical Light Source Efficacy | 110lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle / Viewing Angle | 180° |
Detailed photometric report and IES files available by request
