WPK620 LED Wall Pack Luminaire

Industralight WPK620 is a professional wall mounted luminaire for commercial and industrial projects. The body is manufactured from toughened materials with vandal resistant polycarbonate visor. WPK620 is ideal for general purpose lighting in courtyards, common areas, carparks, security lighting, commercial sites.

Electrical Parameters

Input Voltage 100-277VAC
Max Power Consumption 35W / 50W / 70W / 100W
LED Driver Classification Integral High Efficiency
Light Source Classification Lumileds

Mechanical Specifications

Minimum IK Rating IK10
IP Protection Rating IP65
Nominal Dimensions 269x265mm
Overall Depth From Wall 198mm
Construction Material Aluminium & Polycarbonate
Standard Colour/Finish Black
Recommended Operating Temp -30°C – 45°C

Configuration Options

  • Optional 200-480VAC version by special request
  • DALI dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy 110lm/W
CCT Colour Temperatures 3000K / 4000K / 6500K
Colour Rendering Index [CRI] >80
Beam Angle / Viewing Angle 100°

Detailed photometric report and IES files available by request
