WK955 INDUSTRIAL LINKABLE LED WORK LIGHTS
WK955 series comprises robust, linkable LED work lights, engineered for a wide range of applications including work sites, portable tasks, tunnel lighting, underground mines, and specialized lighting needs. This versatile series ensures consistent, powerful illumination across diverse environments, offering scalability and reliability for the most demanding conditions.
ELECTRICAL PARAMETERS
| Input Voltage: | 100-277VAC or 24VDC |
| Power Consumption: | 20W Per Module |
| LED Driver Classification: | Integral |
| Light Source Classification: | Constant Current SMD LED |
MECHANICAL SPECIFICATIONS
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP65 |
| Total Span Length (extended): | 15.7mtr (5x20W / 31.3mtr (10x20W) |
| Construction Material: | Alloy + Toughened Polycarbonate |
| Standard Colour/Finish | Signal Orange + White |
| Recommended Ambient Temp: | -25 ~ +50°C |
CONFIGURATION OPTIONS
● Available in connected sets of 5x20W or 10x20W
● Available with 3 Pin AU/NZS Flex & Plug by special request
● Up to 2 sets may be interconnected together in line
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | >115lm/W |
| CCT Colour Temperature: | 2700K / 3000K / 4000K / 6500K |
| Colour Rendering (Ra): | Wattage: 20W±5% Per Module |
| Beam Angle/Viewing Angle: | 120° |
COMPLIANCE & CERTIFICATION
● IEC60598 – 100-277VAC 50.60Hz
● IESNA2002
● AS/NZS60598, LM79, LM80
● Lifespan: Exceeds 50,000hrs @ L7
ORDERING INFORMATION
| Model Number: | WK955 |
| Configuration: | 5x20W (15mtr Span ) |
| Specify LED CCT: | 3000K / 4000K / 5000K / 6500K |
| Optional CCT By Request: | 2700K or RGBW |
| Specify Body Colour: | Signal Orange / Black / Custom |
| Specify Voltage Config: | 100-277VAC / 24VDC |
| Plug Options: | AU/NZS Flex & Plug (optional) |
All product details are subject to change without notice. Final specifications may vary.
