WK800 INDUSTRIAL LED WORK LIGHT AREA FLOODLIGHT
WK800 is a collapsible LED work light designed for 360-degree area illumination, featuring an optional tripod stand for versatile positioning. This durable, portable lighting solution is perfect for illuminating work sites and large areas, providing exceptional brightness and coverage to meet the demands of any task. Can be easily transported when folded away and has optional carry case.
ELECTRICAL PARAMETERS
| Input Voltage: | 100-277VAC |
| Power Consumption: | 80W / 120W / 220W |
| LED Driver Classification: | Integrated |
| Light Source Classification: | SMD LED Core |
MECHANICAL SPECIFICATIONS
| Minimum IK Rating: | IKx |
| IP Protection Rating: | IP54 |
| Construction: | Flexible Opalescent Fabric |
| Tripod (Optional): | Extendable >2mtrs |
| Recommended Ambient Temp: | -10 ~ +45°C |
TYPICAL APPLICATIONS
● Readworks, Infrastructure Work Sites, Night Work
● Mining SItes, Construction Sites, After-Hours Inspection Work
● Emergency Services Lighting, Portable Lighting, Task Lighting
● Can be suspended, floor-standing, tripod mount, etc
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | >125lm.W |
| CCT Colour Temperature: | 3000K / 4000K / 5000K / RGBW |
| Colour Rendering (Ra): | >80Ra |
| Beam Angle/Viewing Angle: | 360° |
| MODEL | Power | Diameter | Height |
| WK800W80 | 80W | 265mm | 360mm |
| WK800W120 | 120W | 265mm | 560mm |
| WK800W220 | 220W | 265mm | 820mm |
WK800-TP Tripod (Optional): 2000mm Extended Height. 5.76kg
CONFIGURATION OPTIONS
This product can be customised or configured according to the needs
of your project. Dimming and control options are available by special
request. Control protocols include DALI, Casambi, Wireless, 1-10V,
analogue dimming.
COMPLIANCE & CERTIFICATION
● AS/NZS60598, LM79, LM80
● Service Lifespan: Exceeds 30,000hrs
ORDERING INFORMATION
| WK800W80 | Industrial Portable Area Work Light 80W |
| WK800W120 | Industrial Portable Area Work Light 120W |
| WK800W220 | Industrial Portable Area Work Light 220W |
| WK800-CB | Black Carry Bag Case for WK800 |
| WK800-TP | Extendable Tripod Stand |
| WK800-HK | 350mm Hanging Strap with Buckle |
All product details are subject to change without notice. Final specifications may vary.
