SR203 Surface Mount LED Steplight

Industralight SR203 is a small surface mounted landscape fitting for use in commercial and residential projects. Constructed from die-cast aluminium with a high quality powdercoated finish. SR203 can be wall or ground mounted and is entirely surface mounted making it ideal for installation onto solid block, masonry or concrete surfaces.

Electrical Parameters

Input Voltage 12VDC
Max Power Consumption 3W
LED Driver Classification Remote Constant Voltage
Light Source Classification 3W SMD

Mechanical Specifications

Minimum IK Rating IK10
IP Protection Rating IP67
Mounting Configuration Surface Mounted
Overall Dimensions 68x25mm
Construction Material Machined Aluminium
Standard Colour/Finish Silver / Black / White
Recommended Operating Temp -15°C – 45°C

Configuration Options

  • Non standard colours available by special request
  • PWM dimmable options available by request
  • Remote mounted DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy 85lm/W
CCT Colour Temperatures 3000K / 4000K / 6000K
Colour Rendering Index [CRI] >80
Beam Angle/Viewing Angle 100°

Detailed photometric report and IES files available by request
