Industralight Pantera is a high quality recessed LED downlight luminaire that delivers several advanced features and superior optical performance. Key features include semi-specular aluminium reflector, high efficiency lens, premium quality body and quality constant current LED driver. Pantera is available in several size configurations and is designed for high end commercial interior environments.
Electrical Parameters
Driver Input Voltage
100-240VAC
Max Power Consumption
30W
LED Driver Classification
Remote – Constant Current
Light Source Classification
CREE COB/3XD
Mechanical Specifications
Minimum IK Rating
IK20
Ceiling Cutout
155mm
Trim Diameter
168mm
Overall Depth
182mm
Standard Colour/Finish
White with Silver Reflector
Recommended Operating Temp
-15°C – 45°C
Configuration Options
Custom beam angle by special request
Non standard colours available by special request
DALI dimmable LED driver available by request
Photometric Information
Typical Light Source Efficacy
90lm/W
CCT Colour Temperatures
2700K/ 3000K / 4000K / 6000K
Colour Rendering Index [CRI]
>80 / >95
Beam Angle / Viewing Angle
60°
Detailed photometric report and IES files available by request
