Industralight SQB200 Landscape LED Bollard Spotlight

Industralight SQB200 is a ground mounted LED bollard which can be used for landscape lighting, Illumination of features, sculptures, and other commercial architectural lighting applications. The discrete design houses a twin tilt visor system which gives the user control over the LED light source to deliver unique illumination patters. SQB200 provides smooth indirect illumination with minimal glare or light spillage.

Electrical Parameters

Input Voltage100-240VAC
Max Power Consumption4W
LED Driver ClassificationIntegral 700mA
Light Source ClassificationCREE XPE2

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP65
Overall Height200mm
Body Profile Dimensions100x100mm
Construction Material6063 T5 Aluminium
Standard Colour/FinishDark Grey
Recommended Operating Temp-15°C – 45°C

Configuration Options

  • Custom sizes available by special request
  • 24VDC version available by special request
  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy80lm/W
CCT Colour Temperatures3000K / 4000K / 5000K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle2 x 90° / Twin Adjustable Visor

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberSQB200
Specify Input Voltage200-240VAC / 24VDC
Specify Colour Temp3000K / 4000K / 5000K
Specify Fixture ColourBlack / White / Silver
Warranty InformationExtended Warranty Available
