Rebel® LED Floodlight Series 60W

Industralight Rebel® series is a family of high quality LED floodlight fixtures which can be used for a variety of commercial and industrial lighting applications. Industralight Rebel LED floodlights are supplied integral LED driver and multi-purpose adjustable trunnion bracket. Typical applications include billboards & signage, area floodlighting, pole lighting, container and shipyards, industrial sites, warehousing, streetlighting, security lighting and more.

Electrical Parameters

Input Voltage: 90-305VAC
Power Consumption: 60W
LED Driver Classification: Meanwell HLG Series
Light Source Classification: Luxeon® ES LED

Mechanical Specifications

Minimum IK Rating: IK10
IP Protection Rating: IP65
Adjustable Mounting Bracket: 180° Adjustable Trunnion Bracket
Material/Construction: Toughened Alloy Construction
Nominal Dimensions: 366x327x244mm
Recommended Ambient Temp: -40°C – 50°C

Configuration Options

  • Adjustable mounting bracket included
  • Available in non standard colours by special request
  • 24VDC version available by special request

Photometric Information

Typical Lumen Efficacy: 110lm/W
CCT Colour Temperatures: 3200K/4200K/5000K/6500K
Colour Rendering Index (CRI): >70
Beam Angle/Viewing Angle: 15°/30°/85°/135°x85°

Detailed photometric report and IES files available by request
