NP400E Neptune LED Bunker
Industralight Neptune is a strong impact-resistant light fitting featuring a professional LED light source and an integral constant-current LED driver. NP400E is also available in several sizes and a variety of fascia designs including eyelid and grille options. Typical applications for the NP400E Neptune LED Bunker include mining and industrial sites, government projects, education facilities, and other commercial and industrial projects.
Electrical Parameters
| Input Voltage | 220-240VAC |
| Max Power Consumption | 18W / 24W / 46W |
| LED Driver Classification | Integral Constant Voltage |
| Light Source Classification | OEM SMD2835 |
Mechanical Specifications
| Minimum IK Rating | IK08 / IK10 |
| IP Protection Rating | IP65 |
| Nominal Sizes | 270x270mm / 360x360mm |
| Construction Material | Die Cast Aluminium |
| Standard Colour/Finish | Corrosion Resistant Surface Treatment |
| Recommended Operating Temp | -20°C – 55°C |
Configuration Options
- Also available with grille or plain facia version
- Smaller 130x130mm size available by special request
- DALI dimmable LED driver available by special request
Photometric Information
| Typical Light Source Efficacy | 90lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >85 |
| Beam Angle / Viewing Angle | 120° |
Detailed photometric report and IES files available by request
