NP200P Neptune LED Bunker

Industralight Neptune is a strong impact resistant light fitting featuring a professional LED light source and integral constant current LED driver. NP200 is also available in two sizes and a variety of facia designs including eyelid and grille options. Typical applications include mining & industrial sites, government projects, education facilities, other commercial and industrial projects.

Electrical Parameters

Input Voltage 220-240VAC
Max Power Consumption 18W / 28W / 35W
LED Driver Classification Integral Constant Voltage
Light Source Classification OEM SMD2835

Mechanical Specifications

Minimum IK Rating IK08 / IK10
IP Protection Rating IP65
Nominal Dimensions 214x130mm / 275x180mm / 340x210mm
Construction Material Die Cast Aluminium
Standard Colour/Finish Corrosion Resistant Surface Treatment
Recommended Operating Temp -20°C – 55°C

Configuration Options

  • Also available with grille or eyelid facia version
  • Non standard colours available by special request
  • DALI dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy 90lm/W
CCT Colour Temperatures 3000K / 4000K / 6500K
Colour Rendering Index [CRI] >85
Beam Angle / Viewing Angle 120°

Detailed photometric report and IES files available by request
