NP200P Neptune LED Bunker
Industralight Neptune is a strong impact resistant light fitting featuring a professional LED light source and integral constant current LED driver. NP200 is also available in two sizes and a variety of facia designs including eyelid and grille options. Typical applications include mining & industrial sites, government projects, education facilities, other commercial and industrial projects.
Electrical Parameters
| Input Voltage | 220-240VAC |
| Max Power Consumption | Several Options 9W – 46W |
| LED Driver Classification | Integral Constant Voltage |
| Light Source Classification | OEM SMD2835 |
Mechanical Specifications
| Minimum IK Rating | IK08 / IK10 |
| IP Protection Rating | IP65 |
| Nominal Dimensions | 214x130mm / 275x180mm / 340x210mm |
| Construction Material | Die Cast Aluminium |
| Standard Colour/Finish | Corrosion Resistant Surface Treatment |
| Recommended Operating Temp | -20°C – 55°C |
Configuration Options
- Also available with grille or eyelid facia version
- Non standard colours available by special request
- DALI dimmable LED driver available by special request
Photometric Information
| Typical Light Source Efficacy | 90lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >85 |
| Beam Angle / Viewing Angle | 120° |
Detailed photometric report and IES files available by request
