Industralight MTX108W High Power LED Projector Floodlight

Industralight MTX108 is a high-powered commercial-grade LED floodlight projector capable of illuminating large scale architecture, building facades, structures and sculptures, large scale wall-washing. Industralight MTX fittings are available with various beam angles, mounting configurations and LED colour output options including RGB with DMX control.

Electrical Parameters

Driver Input Voltage:90-260VAC
Power Consumption:108W
LED Driver Classification:Integral, Constant Current
Light Source Classification:3W High Power LED

Mechanical Specifications

Minimum IK Rating:IK06
IP Protection Rating:IP65
Nominal Dimensions:310 x 300 x 290mm
Standard Fixture Colour:Silver Powdercoat
Material:Die Cast Alloy

Configuration Options

  • Can be gang-mounted in banks of 2,4,6,8 fixtures
  • DALI dimmable version available by special request

Photometric Information

Typical Lumen Efficacy:110lm/W
CCT Colour Temperatures:3200K / 4200K / 6500K / RGB
Colour Rendering Index (CRI):Up to 85Ra
Possible LED Output Colours:16.7 Million (RGB Version)
Beam Angle/Viewing Angle:15° / 35° / 45°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details.

Series Model Number:MTX Series
Specify Colour Temp:3200K/4200K/6500K/RGB
Specify Beam Angle:15° / 35° / 45°
RGB Option:RGB with Built in DMX
Input Voltage:90-260VAC
Optional Accessories:Barn Doors or Anti Glare Louvre
Mounting Brackets:Various Multi-Gang Mount Brackets
