Industralight LCS202 LED Landscape Spotlight

Industralight LCS202 is a premium quality landscape fitting for garden lighting, pathway lighting, task lighting and discrete illumination of other landscape features. The fitting is constructed from steel and finished with a corrosion resistant bronzed plating or anodised surface treatment. LCS202 is supplied with garden spike for versatile installation. Several other mounting options are also available.

Electrical Parameters

Input Voltage12VDC / 24VDC / 240VAC
Max Power Consumption6W / 10W
LED Driver ClassificationIntegral (240VAC) / Remote Mounted (12VDC)
Light Source ClassificationCREE CXA1507
Optional RGB ConfigurationRGB (12VDC or 24VDC Only)

Mechanical Specifications

Minimum IK RatingIK09
IP Protection RatingIP67
Dimensions – Body Diameter500mm / 1000mm
Dimensions – Body Length145mm
Overall Height  315mm including Spike
Construction MaterialPlated Aluminium High Corrosion Resistance
Available FinishSilver Plated / Aged Bronze

Configuration Options

  • Non standard colours available by special request
  • Dali dimmable LED driver available by request
  • RGB/RGBW control options available by request

Photometric Information

Typical Light Source Efficacy95lm/W
CCT Colour Temperatures3000K / 4000K / 6000K / RGB
Colour Rendering Index [CRI]>85
Beam Angle/Viewing Angle30° / 60°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberLCS202
Input Voltage12VDC / 24VDC / 240VAC
Specify Colour Temp3000K / 4000K / 6500K
Optional RGB/W ConfigurationRGB / RGBW
Specify Wattage6W / 10W
Specify Beam Angle30° / 60°
Warranty InformationExtended Warranty Available
