Industralight RDL1431 LED downlights feature high integrity IP67 rating which makes them suitable for demanding commercial industrial environments. The fixtures have a 316 marine-grade stainless steel trim and integral control gear.
Electrical Parameters
Input Voltage:
100-240VAC
Power Consumption:
26W
LED Driver Classification:
Integral Constant Current
Light Source Classification:
CXA-2520 LED
Mechanical Specifications
Minimum IK Rating:
IK10
IP Protection Rating:
IP67
Nominal Diameter:
278mm Trim
Glass Lens Type:
12mm Tempered Glass Lens
Material/Construction:
Alloy & Stainless Steel Trim
Recommended Ambient Temp:
-20°C – 45°C
Configuration Options
Can be finished in black or silver
Non-standard colour finishes available by special request
Dimmable LED driver can be factory fitted by special request
Wire suspension support harness included
Photometric Information
Typical Lumen Efficacy:
110lm/W
CCT Colour Temperatures:
3200K/4200K/5000K/6500K
Colour Rendering Index (CRI):
>75
Viewing Angle:
75°
Detailed photometric report and IES files available by request
