Industralight IXR 200W Surface-Mount LED Canopy Light

Industralight IXR is a professional surface mounted LED canopy floodlight which can be used for general purpose commercial lighting, floodlighting, highbay/ lowbay lighting, tunnel lighting and other industrial lighting applications. The fixtures have modular LED light source and are available in various models including custom sizes by request

Electrical Parameters

Driver Input Voltage:100-305VAC
Power Consumption:200W
LED Driver Classification:Integral, Constant Current
Light Source Classification:Luxeon® T-Chip LED

Mechanical Specifications

Minimum IK Rating:IK06
IP Protection Rating:IP65
Nominal Dimensions:303x473x183mm
Material:Powdercoated Alloy

Configuration Options

  • Also available in 24VDC version
  • Frame colour can be refinished
  • 1-10V dimmable option by special request
  • Custom frame sizes available by special request

Photometric Information

Typical Lumen Efficacy:110lm/W
CCT Colour Temperatures:3000K/4000K/5000K/6500K
Colour Rendering Index (CRI):>75
Beam Angle/Viewing Angle:100°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details

Series Model Number:IXR200S (200W)
Specify Colour Temp:3000K/4000K/5000K/6500K
Optional Mounting:Adjustable Pole-Mount Bracket
Specify Colour:Black  or  White
Specify Voltage Type:100-305VAC or 24VDC

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
