IGR9210 Inground LED Uplight
Industralight IGR9210 is a commercial grade inground luminaire with integrated LED light source and advanced optical configuration. The luminaire is constructed from marine grade stainless steel and toughened tempered glass lens. Available with single colour or RGB/RGBW LED light source. IGR9210 is supplied with PVC mounting housing.
Electrical Parameters
| Input Voltage | 24VDC |
| Max Power Consumption | 10W |
| LED Driver Classification | Constant Voltage |
| Light Source Classification | CREE 10W |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP67 |
| Overall Trim Diameter | 116mm |
| Fitting Depth | 53mm |
| Overall Depth in Housing | 110mm |
| Construction Material | 316 Stainless Steel |
| Recommended Operating Temp | -20°C – 50°C |
Configuration Options
- Trim can be powdercoated by special request
- RGB / RGBW Configuration available by request
- Remote mounted DALI dimmable LED driver available by special request
Photometric Information
| Typical Light Source Efficacy | 100lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 5000K / RGB / RGBW |
| RGB Control Range | 0-100% 256-bit |
| Colour Rendering Indec [CRI] | >80 |
| Beam Angle/Viewing Angle | 15° / 24° / 38° / 100° |
Detailed photometric report and IES files available by request
