Industralight EXP Express LED Highbay

Industralight EXP Express series LED Highbay is a conventionally styled LED Highbay for use in warehouses, manufacturing facilities, industrial areas and other large scale lighting applications. EXP LED Highbays feature incorporate integral LED control gear, advanced thermal management for cooling and are also dimmable via 1-10V analogue signal or DALI by special request.

Electrical Parameters

Input Voltage100-265VAC
Max Power Consumption100W / 120W / 150W / 200W / 250W
LED Driver ClassificationIntegral 1-10V Dimmable
Light Source ClassificationSMD LED Modular
Standard Dimming Configurations1-10V Dimmable

Mechanical Specifications

Minimum IK RatingIK08
IP Protection RatingIP65
Max Diameter500mm
Max Overall Height640mm
Construction MaterialAluminum Heatsink
Recommended Operating Temp-20°C – 55°C

Configuration Options

  • Prismatic polycarbonate refractor accessory available
  • Multiple reflector angle configurations can be specified
  • Daylight harvesting controls can be integrated by epical request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy115lm/W
CCT Colour Temperatures3000K / 4000K / 5000K / 6000K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle45° / 90° / 120°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberEXP Express
Specify Wattage100W / 120W / 150W / 200W / 250W
Specify Colour Temp3000K / 4000K / 5000K / 6000K
Specify Beam Angle45° / 90° / 120°
Dimming Configuration1-10V / DALI / Non-Dimmable
Warranty InformationExtended Warranty Available
