ATP168 LED LANDSCAPE PROJECTOR
ATP168 is a professional-grade architectural LED floodlight designed with commercial-quality materials and exceptional optical performance. It offers customizable options including various beam angles, multiple mounting configurations, and a range of LED options. Suitable for wide applications, illuminating building facades, sculptures, wall washing, commercial floodlighting, architectural interiors and exteriors, as well as streetscape and landscape lighting projects, pole mounting.
ELECTRICAL PARAMETERS
| Input Voltage: | 90-265VAC / 24VDC |
| Power Consumption: | 20W / 25W |
| LED Driver Classification: | Integral, Constant Current |
| Light Source Classification: | Single CREE COB-LED |
MECHANICAL SPECIFICATIONS
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP66 |
| Nominal Dimensions: | 102(dia)x168mm(length) |
| Construction Material: | Powdercoated High-Grade Alloy |
| Standard Colour/Finish: | Matt White / SIlver / Matt Black |
| Recommended Ambient Temp: | -20˚C – 65˚C |
CONFIGURATION OPTIONS
- Adjustable bracket with round base included
- Several optional mounting configurations available
- 24VDC version available by request
- Custom luminaire colours available by special request
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | 110lm/W |
| CCT Colour Temperature: | 2700K/3000K/4000K/6500K |
| Colour Rendering (Ra): | >85Ra |
| Beam Angle/Viewing Angle: | 15˚ / 24˚ / 36˚ / 60˚ |
CONTROL OPTIONS
This product can be customised or configured according to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
COMPLIANCE & CERTIFICATION
- IESNA2002
- AS/NZS60598, LM79, LM80
- Lifespan: Exceeds 50,000hrs @ L70
ORDERING INFORMATION
| Model Number: | ATP168 |
| Specify LED CCT: | 2700K/3000K/4000K/6500K |
| Specify Beam Angle: | 15˚ / 24˚ / 36˚ / 60˚ |
| Specify Finish/Colour: | Gunmetal Silver |
| Input Voltage Option: | 85-265VAC or 24VDC |
| Dimming Option: | Non-Dim / DALI / Phase Dim / DMX |
All product details are subject to change without notice. Final specifications may vary.
