Gecko® AM2318 Multi-Purpose LED Worklight/Floodlight

Industralight Gecko fittings are multi-purpose LED spotlights that can be used for a wide range of applications. They are a compact design and work on wide voltage range of 9-27VDC. They are ideal for industrial projects, automotive & security applications, task lighting, vehicles, marine applications, machinery, mining and industrial equipment etc.

Electrical Parameters

Input Voltage: 9-27VDC
Power Consumption: 18W
LED Driver Classification: Constant Voltage Input
Light Source Classification: CREE XR High Power LED

Mechanical Specifications

Minimum IK Rating: IK08
IP Protection Rating: IP67
Nominal Dimensions: 123x132x54mm
Material: Extruded Alloy + Stainless Steel Brackets

Configuration Options

  • Adjustable stainless steel mounting brackets included
  • Special LED colours available by special request
  • Available in different beam angles

Photometric Information

Typical Lumen Efficacy: 85lm/W
CCT Colour Temperatures: 6500K
Colour Rendering Index (CRI): >85
Beam Angle/Viewing Angle: 30°  or  60°

Detailed photometric report and IES files available by request

Download data sheet Talk to a specialist
