Industralight Gecko® AM2318 Multi-Purpose LED Worklight/Floodlight

Industralight Gecko fittings are multi-purpose LED spotlights that can be used for a wide range of applications. They are a compact design and work on wide voltage range of 9-27VDC. They are ideal for industrial projects, automotive & security applications, task lighting, vehicles, marine applications, machinery, mining and industrial equipment etc.

Electrical Parameters

Input Voltage:9-27VDC
Power Consumption:18W
LED Driver Classification:Constant Voltage Input
Light Source Classification:CREE XR High Power LED

Mechanical Specifications

Minimum IK Rating:IK08
IP Protection Rating:IP67
Nominal Dimensions:123x132x54mm
Material:Extruded Alloy + Stainless Steel Brackets

Configuration Options

  • Adjustable stainless steel mounting brackets included
  • Special LED colours available by special request
  • Available in different beam angles

Photometric Information

Typical Lumen Efficacy:85lm/W
CCT Colour Temperatures:6500K
Colour Rendering Index (CRI):>85
Beam Angle/Viewing Angle:30°  or  60°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details.

Model Number:AM2318
Specify Colour Temp:6500K (other LED colours available)
Specify Beam Angle:30° / 60°
Wattage:18W
