EURO160SS LED BOLLARD SERIES 160MM
Industralight Euro® 160mm LED Bollards is a professional solution for walkways, pathways and security lighting application for a wide range of projects. Euro® 160SS LED Bollards are constructed from solid 316L marine grade stainless steel, and offer the highest quality bollard construction available. Euro incorporate high efficiency LED components and integral LED control gear.
ELECTRICAL PARAMETERS
| Input Voltage: | 100-265VAC |
| Power Consumption: | 15W / 20W |
| LED Driver Classification: | Integral, Constant Current |
| Light Source Classification: | XP-E Power CREE LED |
MECHANICAL SPECIFICATIONS
| Body Diameter: | 160mm |
| IP Protection Rating: | IP65 |
| Overall Height Options: | 1000mm |
| Construction Material: | 316L Stainless Steel |
| Standard Colour/Finish: | Brushed Stainless |
| Recommended Ambient Temp: | -20˚C – 45˚C |
CONFIGURATION OPTIONS
● Custom Height Also Available
● 24VDC Input Voltage by Special Request
● Tunable CCT by Special Request
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | 90lm/W |
| CCT Colour Temperature: | 3000K/4000K/6500K |
| Colour Rendering (Ra): | >80Ra |
| Beam Angle/Viewing Angle: | 360˚ Illumination |
CONFIGURATION OPTIONS
Euro® LED Bollards can be customised or configured according to the
needs of your project. Custom powdercoat options. Dimming and
control protocols include DALI, Casambi, Wireless, 1-10V, analogue
dimming.
COMPLIANCE & CERTIFICATION
● IESNA2002
● AS/NZS60598, LM79, LM80
● Lifespan: Exceeds 50,000hrs @ L70
ORDERING INFORMATION
| Series: | EURO160SS (160mm Dia) |
| Height Option: | 1000mm / Custom |
| Specify LED Power: | 15W / 20W / Other:__________ |
| Specify LED CCT: | 3000K / 4000K / 6500K / CCT Tunable |
| Specify Top: | 100-265VAC or 24VDC |
| Specify Finish/Colour: | Brushed Stainless / Custom Finish |
| Optional Accessory: | PE Auto Daylight Switch |
| Dimming Option | Non Dimmable / DALI / Phase Dimmable |
All product details are subject to change without notice. Final specifications may vary.
