ALT335R RECESSED IP65 LED WALL LIGHT
ALT335R is a recessed brick light luminaire with robust design suitable for commercial lighting, residential lighting and industrial locations. Integral constant current LED and on board LED driver. Corrosion resistant marine grade surface treatment. And fully sealed design provide for long lifespan. Suits all indoor and outdoor locations.
Electrical Parameters
| Input Voltage: | 100-240VAC |
| Power Consumption: | 13W |
| LED Driver Classification: | Integral LED Driver |
| Light Source Classification: | Osram 3030 SMD LED |
Mechanical Specifications
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP65 |
| Nominal Dimensions: | 250x98x90mm |
| Construction Material: | Cast Aluminium, Powdercoated |
| Standard Colour/Finish: | Dark Grey / Black / White |
| Recommended Ambient Temp: | -10 ~ +50°C |
Configuration Options
- Surface mounted version also available (ALT550S)
- Non standard colours available by special request
- DALI dimmable LED driver available by request
Photometric Information
| Typical Lumen Efficacy: | 105lm/W |
| CCT Colour Temperature: | 3000K / 4000K / 6000K |
| Colour Rendering (Ra): | >80Ra |
| Beam Angle/Viewing Angle: | 60° / Indirect Visor |
Control Options
ALT335R is supplied with PVC mounting can. The LED configuration can be customised to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
