WPK400 Adjustable Wall Pack Luminaire
WPK400 wall pack is a versatile lighting solution with a variable adjustable tilt feature. The luminaire can be positioned for an optimal mix of direct or indirect illumination. Toughened construction for all exterior locations and harsh environments. Typical applications for the WPK400 wall pack include commercial and industrial lighting, landscape lighting, security lighting, building facades, courtyards, floodlighting, and task lighting. WPK is now available in two model sizes with selectable CCT and LED power options.
Electrical Parameters
| Input Voltage | 120-277VAC |
| Power Options | 15W-30W / 40W-80W |
| LED Driver Classification | Integral Constant Current |
| Light Source Classification | Lumileds COB |
Mechanical Specifications
| Minimum IK Rating | IK10 |
| IP Protection Rating | IP66 |
| Dimensions | Refer to Data Sheet |
| Construction Material | Powdercoated Aluminium |
| Standard Colour/Finish | Black |
| Recommended Operating Temp | -10°C – +50°C |
Configuration Options
- Non standard fitting colours available by special request
- Optional PE sensor for automatic daylight control
Photometric Information
| Typical Light Source Efficacy | 130lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 5000K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle / Viewing Angle | 90° |
Detailed photometric report and IES files available by request
