W3370 IP65 LED WALL LUMINAIRE
W3370 is a commercial grade wall light with solid extruded body, and powdercoated. Corrosion resistant marine grade finish makes the product good for use in all exterior locations. The clear polycarbonate base allows for subtle indirect illumination to filter through the edge.
Electrical Parameters
| Input Voltage: | 90-265VAC |
| Power Consumption: | 10W |
| LED Driver Classification: | Constant Current |
| Light Source Classification: | Osram SMD3030 LED |
Mechanical Specifications
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP65 |
| Overall Length | 230mm |
| Body Height: | 80mm |
| Overall Projection From Wall: | 33mm |
| Construction Material: | Aluminium |
| Standard Colour/Finish: | Black / White / Custom |
| Recommended Ambient Temp: | -15°C – 55°C |
Configuration Options
- Non standard colours available by special request
- Remote mounted DALI dimmable LED driver available
- Also available in Smaller size option ( 175x83x64mm)
- Several other sizes and options available in W6300 series
Photometric Information
| Typical Lumen Efficacy: | 90lm/W |
| CCT Colour Temperature: | 3000K / 4000K / 6000K / RGBW |
| Colour Rendering (Ra): | >85Ra |
| Beam Angle/Viewing Angle: | 100° |
Control Options
W3370 can be customised or configured according to the needs of your project. Remote mounted LED driver is available option with control protocols including DALI, Casambi, Wireless, 1-10V, analogue dimming, phase dimming.
