TWL601 IP65 LED Wall Light

Industralight TWL601 is an external LED wall light with high-quality LED light source components. The fitting is constructed from extruded aluminium and features corrosion resistant powdercoated surface treatment. TWL601 is suited to commercial and residential projects where a high quality architectural design is preferred.

Electrical Parameters

Input Voltage 100-240VAC
Max Power Consumption 13W
LED Driver Classification HEP Integral Constant Current
Light Source Classification Sharp Zenigata COB LED

Mechanical Specifications

Minimum IK Rating IK09
IP Protection Rating IP65
Overall Height 150mm
Body Profile Dimensions 55x55mm
Overall Projection From Wall 96mm
Construction Material Aluminium
Standard Colour/Finish Black / White / Silver
Recommended Operating Temp -15°C – 55°C

Configuration Options

  • Non standard colours available by special request
  • Remote mounted DALI dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy 115lm/W
CCT Colour Temperatures 3000K / 4000K / 6000K
Colour Rendering Index [CRI] >85
Beam Angle / Viewing Angle 10° / 30° / 55°

Detailed photometric report and IES files available by request
