Industralight SQR500Y15 Architectural LED Landscape Floodlight

Industralight SQR500Y15 is a high quality architectural LED floodlight that features commercial grade materials and superior optical performance. The fixtures can be customised with different beam angles, mounting options and a variety of LED colour temperatures including RGB for fully controllable colour spectrum output.  Typical applications include building facades, sculpture illumination, wall washing, commercial floodlighting, architectural interiors and exteriors, streetscape and landscape illumination.

Electrical Parameters

Input Voltage:90-265VAC
Power Consumption:28W
LED Driver Classification:Integral, Constant Current
Light Source Classification:CREE XP-LED

Mechanical Specifications

Minimum IK Rating:IK06
IP Protection Rating:IP66
Nominal Dimensions:362x127x146mm
Material:Powdercoated High-Grade Alloy

Configuration Options

  • Adjustable Y bracket included
  • 24VDC version available by request
  • Custom fixture colours available by special request

Photometric Information

Typical Lumen Efficacy:83lm/W
CCT Colour Temperatures:3000K/4000K/6500K/RGB
Typical Colour Rendering Index (CRI):>85
Beam Angle/Viewing Angle:6° / 12° / 30° / 48° / 12×48°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty. Please see our warranty policy for full details.

Series Model Number:SQR500Y15 (Y Bracket)
Specify LED Colour Temp:3000K/4000K/6500K/RGB
Beam Angle:6° / 12° / 30° / 48° / 12×48°
Specify Colour:Gunmetal Silver
Voltage Type:85-265VAC  or  24VDC
