MTR665 Meteor Series LED Wall Fixture

Industralight MTR665 is a n industrial grade LED luminaire suitable for commercial wall mounted applications. The fitting features a toughened ADC metal construction with 3mm tempered glass visor. Typical applications include shopping precincts public spaces, courtyards, restaurants and hospitality projects, building highlighting, hospitals & schools, government sectors, other commercial projects.

Electrical Parameters

Input Voltage 110-240VAC
Max Power Consumption 25W
LED Driver Classification Integral Meanwell LED Driver
Light Source Classification CREE CXA1816

Mechanical Specifications

Minimum IK Rating IK09
IP Protection Rating IP65
Dimensions 200x190x180mm
Construction Material Die-Cast + 3mm Tempered Glass
Standard Colour/Finish Dark Charcoal
Recommended Operating Temp -10°C – 45°C

Configuration Options

  • Non standard fitting colours available by special request
  • DALI dimmable configuration by special request

Photometric Information

Typical Light Source Efficacy 85lm/W
CCT Colour Temperatures 3000K / 4000K / 6000K
Colour Rendering Index [CRI] >85
Beam Angle / Viewing Angle 32°

Detailed photometric report and IES files available by request



Download data sheet Talk to a specialist
