MTR665 Meteor Series LED Wall Fixture
Industralight MTR665 wall-mounted industrial-grade LED luminaire is suitable for commercial wall-mounted applications. The fitting features a toughened ADC metal construction with a 3mm tempered glass visor. Typical applications for the MTR665 wall-mounted fitting include:
- Shopping precincts
- Public spaces
- Courtyards and plazas
- Restaurants and hospitality projects
- Building highlighting
- Hospitals and
- Education facilities and schools
- Government sectors and structures
Electrical Parameters
| Input Voltage | 110-240VAC |
| Max Power Consumption | 25W |
| LED Driver Classification | Integral Meanwell LED Driver |
| Light Source Classification | CREE CXA1816 |
Mechanical Specifications
| Minimum IK Rating | IK09 |
| IP Protection Rating | IP65 |
| Dimensions | 200x190x180mm |
| Construction Material | Die-Cast + 3mm Tempered Glass |
| Standard Colour/Finish | Dark Charcoal |
| Recommended Operating Temp | -10°C – 45°C |
Configuration Options
- Non standard fitting colours available by special request
- DALI dimmable configuration by special request
Photometric Information
| Typical Light Source Efficacy | 85lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6000K |
| Colour Rendering Index [CRI] | >85 |
| Beam Angle / Viewing Angle | 32° |
Detailed photometric report and IES files available by request
