MTR204 LED Landscape Spotlight
Industralight MTR204 is a professional outdoor landscape spotlight with high efficiency LED light source and toughened magnesium alloy construction. MTR204 is designed for highlighting gardens, trees, sculptures and other outdoor or landscape features. Suitable for commercial or residential projects.
Electrical Parameters
| Input Voltage | 220-240VAC / 12VDC |
| Max Power Consumption | 5W |
| LED Driver Classification | Integral (240V) or Remote (12VDC) |
| Light Source Classification | CREE CXA |
Mechanical Specifications
| Minimum IK Rating | IK09 |
| IP Protection Rating | IP65 |
| Dimensions – Head Diameter | 66mm |
| Dimensions – Overall Height | 626mm |
| Construction Material | High Pressure Die Cast Aluminium |
| Standard Colour/Finish | Corrosion Resistant UV Surface Treatment |
| Recommended Operating Temp | -20°C – 45°C |
Configuration Options
- Non standard colours available by special request
- DALI dimmable LED driver available by request
- Available with surface mounted post
Photometric Information
| Typical Light Source Efficacy | 110lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >85 |
| Beam Angle/Viewing Angle | 30° / 60° |
Detailed photometric report and IES files available by request
