LUS653R CONTINUOUS LINEAR LED LUMINAIRE
LUS653R is a recessed linear LED light suitable for commercial projects. LUS653 is supplied with recesseding spring clips for direct recess installation into gyprock and plaster ceilings. Industralight offers dimmable and custom versions. Industralight ensures that the linear LED design can be both dimmable and customized to specific requirements, reinforcing its position as a leader in linear LED innovations.
ELECTRICAL PARAMETERS
| Input Voltage: | 100-240VAC |
| Power Consumption: | 18-72W per mtr |
| LED Driver Classification: | Integral Constant Voltage |
| Light Source Classification: | Osram Duris® E2835 |
MECHANICAL SPECIFICATIONS
| Minimum IK Rating: | IK08 / IK10 |
| IP Protection Rating: | IP20 / IP65 |
| Profile Dimensions: | 65x35mm |
| Construction Material: | Extruded Aluminium |
| Standard Colour/Finish: | Black / White / Custom |
| Recommended Ambient Temp: | -15˚C – 45˚C |
CONFIGURATION OPTIONS
● Optional toughened polycarbonate diffuser IK10
● Profile colour can be refinished by special request
● DALI dimmable LED driver available by request
● CCT Tunable LED with DT8 DALI Control by Special Request
PHOTOMETRIC INFORMATION
| Typical Lumen Efficacy: | 110-120lm/W |
| CCT Colour Temperature: | 3000K / 4000K / 5000K / 6000K |
| Colour Rendering (Ra): | >80 / >90Ra |
| Beam Angle/Viewing Angle: | 110˚ |
CONFIGURATION OPTIONS
This product can be customised or configured according to the needs of your project. Dimming and control options are available by special request. Control protocols include DALI, Casambi, Wireless, 1-10V, analogue dimming.
COMPLIANCE & CERTIFICATION
● IESNA2002
● AS/NZS60598, LM79, LM80
● Lifespan: Exceeds 50,000hrs @ L70
ORDERING INFORMATION
| Model Number: | LUS653R |
| Specify Mounting: | Recessed with Spring Clips |
| Specify LED Wattage: | 18W – 48W |
| Input Voltage Option: | 100-240VAC / 24VDC |
| Dimming Option: | DALI / 1-10V / PWM / Non-Dim |
| Continuous Lengths: | Custom As Required |
All product details are subject to change without notice. Final specifications may vary
