LCS206 LED Landscape Spotlight
Industralight LCS206 is a premium quality landscape fitting for garden lighting, pathway lighting, task lighting and discrete illumination of other landscape features. The fitting is constructed from steel and finished with a corrosion resistant bronzed plating or anodised surface treatment. LCS206 is supplied with garden spike for versatile installation. Several other mounting options are also available.
Electrical Parameters
| Input Voltage | 12VDC / 24VDC / 240VAC |
| Max Power Consumption | 6W / 10W |
| LED Driver Classification | Integral (240VAC) / Remote Mounted (12VDC) |
| Light Source Classification | CREE CXA1507 |
| Optional RGB Configuration | RGB (12VDC or 24VDC Only) |
Mechanical Specifications
| Minimum IK Rating | IK09 |
| IP Protection Rating | IP67 |
| Dimensions – Body Diameter | 58mm |
| Dimensions – Body Length | 95mm |
| Overall Height | 300mm including Spike |
| Construction Material | Plated Aluminium High Corrosion Resistance |
| Available Finish | Silver Plated / Aged Bronze |
Configuration Options
- Non standard colours available by special request
- Dali dimmable LED driver available by request
- RGB/RGBW control options available by request
Photometric Information
| Typical Light Source Efficacy | 95lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6000K / RGB |
| Colour Rendering Index [CRI] | >85 |
| Beam Angle/Viewing Angle | 30° / 60° |
Detailed photometric report and IES files available by request
