INRL80 Catenary Mount LED Fixture
Industralight INRL80 is an industrial catenary mount fixture for general purpose illumination. The body is manufactured from high-density cast aluminium with corrosion resistant powdercoated surface treatment. INRL80 has a clasp mounting system which allows installation onto catenary. Industralight can provide a full catenary mounting system by request.
Electrical Parameters
| Input Voltage | 100-277VAC |
| Max Power Consumption | 88W |
| LED Driver Classification | Integral Constant Current |
| Light Source Classification | CREE Modular – XPE2 |
Mechanical Specifications
| Minimum IK Rating | IK09 |
| IP Protection Rating | IP66 |
| Nominal Diameter | 500mm |
| Overall Height | 276mm |
| Standard Colour/Finish | Corrosion Resistant Surface Treatment |
| Mounting Method | Integral Catenary Wire Clasp OD:6-12mm |
| Recommended Operating Temp | -35°C – +55°C |
Configuration Options
- Other wattage sizes available by special request
- Non standard colours available by special request
- DALI dimmable LED driver available by special request
Photometric Information
| Typical Light Source Efficacy | 95lm/W |
| CCT Colour Temperatures | 3000K / 4000K / 6500K |
| Colour Rendering Index [CRI] | >80 |
| Beam Angle/Viewing Angle | 135°x85° |
Detailed photometric report and IES files available by request
