Industralight SDL925 Square Surface Mount LED Downlight

Industralight SDL surface mounted LED downlights are a square, compact and stylish fitting for locations that require a surface mounted downlight solution. The fittings have integral LED driver and are protected to IP65 making them suitable for all indoor and outdoor applications.

Electrical Parameters

Input Voltage:100-265VAC
Power Consumption:11W or 23W Options
LED Driver Classification:Integral Constant Current
Light Source Classification:XP-E LED


Mechanical Specifications

Minimum IK Rating:IK06
IP Protection Rating:IP65
Nominal Dimensions:150x150x150mm
Material/Construction:Extruded Alloy/Powdercoated
Recommended Ambient Temp:-20°C – 45°C


Configuration Options

  • 24VDC version available by special request
  • Non-standard colour finishes available by special request


Photometric Information

Typical Lumen Efficacy:85-95lm/W
CCT Colour Temperatures:3200K/4200K/6500K
Colour Rendering Index (CRI):>85
Beam Angle/Viewing Angle:24° or 60°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.  Please see our warranty policy for full details.width=”50%”

Series Model Number:SDL925
Specify Colour Temp:  3200K/4200K/6500K
Specify Beam Angle:24°  or  60°
Specify Colour:Black or Matt Grey
 Voltage:85-265VAC

All product specifications are subject to change without notice. Industralight assumes no responsibility of errors or omissions. Please confirm product details prior to ordering.
