Industralight IGR9103 Inground LED Uplight

Industralight IGR9103 is a commercial grade inground uplight luminaire with integrated LED light source and advanced optic. The luminaire is constructed from marine grade stainless steel and toughened tempered glass lens. IGR9103 is supplied with PVC mounting housing.

Electrical Parameters

Input Voltage12VDC
Max Power Consumption3W
LED Driver ClassificationConstant Voltage
Light Source ClassificationCREE 3W

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP67
Trim Diameter58mm
Overall Mounting Depth55mm
Construction Material316 Stainless Steel
Recommended Operating Temp-20°C – 50°C

Configuration Options

  • Trim can be powdercoated by special request
  • Square version available by special request
  • Remote mounted DALI dimmable LED driver available by special request

Photometric Information

Typical Light Source Efficacy100lm/W
CCT Colour Temperatures3000K / 4000K / 5000K / RGB
RGB Control Range0-100% 256-bit
Colour Rendering Indec [CRI]>80
Beam Angle/Viewing Angle15° / 30° / 60°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberIGR9103
Specify Colour Temp3000K / 4000K / 5000K / RGB
Optional RGB ConfigurationRGB / DMX512 / PWM Controller
Beam Angle15° / 30° / 60°
Included AccessoryInground Mounting Housing
Warranty InformationExtended Warranty Available
