DL6618 series is a commercial style LED downlight series that can be used for high end interior projects. Incorporating high performance COB LED modules and are available in a wide range of beam angle options and other configuration options. Used in commercial spaces, galleries, museums, hospitality, offices, etc.

Electrical Parameters

Driver Input Voltage: 220-240VAC
Power Consumption: 14W / 18W / 24W / 35W
LED Driver Classification: Constant Current
Light Source Classification: CREE® COB LED

Mechanical Specifications

Installation: Ceiling Recessed
IP Protection Rating: IP20
Fixture Material: Aluminium Construction
Colour Finish: White Trim + Silver Reflector
Fixture Style: Gimbal And 270deg Swivel
Trim Diameter: 205mm
Ceiling Cutout: 190mm

Configuration Options

  • Non standard trim colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Lumen Efficacy: 130lm/W
CCT Colour Temperatures: 3200K/4200K/6500K
Colour Rendering Index (CRI): >80
Beam Angle/Viewing Angle: 24˚ / 40˚ / 60
