Industralight PHB200 Architectural LED Highbay

Industralight PHB200 is an architecturally styles LED Highbay luminaire for high-end projects. The fitting features a solid alloy construction with tempered glass visor. The architectural design makes the product ideal for industrial or commercial environments, gymnasiums, entertainment venues, shopping malls and arcades, other commercial projects.  PHB200 is also available in a variety of size configurations.

Electrical Parameters

Input Voltage85-266VAC
Max Power Consumption200W
LED Driver ClassificationIntegral
Light Source ClassificationHigh Power T20 LED

Mechanical Specifications

Minimum IK RatingIK10
IP Protection RatingIP65
Body Dimensions52x49mm
Construction MaterialDie Cast Aluminium
Standard Colour/FinishCorrosion Resistant
Recommended Operating Temp-40°C – 50°C

Configuration Options

  • Also available in smaller sizes, 30W / 50W / 100W
  • Non standard colours available by special request
  • DALI dimmable LED driver available by request

Photometric Information

Typical Light Source Efficacy90lm/W
CCT Colour Temperatures3000K / 4000K / 6500K
Colour Rendering Index [CRI]>80
Beam Angle/Viewing Angle80°

Detailed photometric report and IES files available by request

Lighting Design & Simulations

Industralight can provide independent LUX calculations and 3D lighting simulations for your project incorporating this product. Please contact our office for more information on design services.

Warranty Information

Industralight fixtures are manufactured to a high quality standard using finest quality LED components and materials. This product is covered by a full product replacement warranty.

Please see our warranty policy for full details.

Series Model NumberPHB200
Specify Wattage200W
Specify Colour Temp3000K / 4000K / 6500K
Specify Fixture ColourSilver / Black
Warranty InformationExtended Warranty Available
