MFV230 REGAL® HIGH MAST LED FLOODLIGHT
Regal® MFV is a modular LED floodlight luminaire for use in sports stadiums, large sports fields, industrial areas and a variety of other commercial lighting and industrial lighting applications. MFV features increased lumen performance and a new multi purpose bracket design with with more mounting functionality for all lighting applications. All components are modular are replaceable for future service and maintenance.
Electrical Parameters
| Input Voltage: | 90-305VAC |
| Power Consumption: | 230W |
| LED Driver Classification: | Meanwell, ELG Constant Current |
| Light Source Classification: | Luxeon® ES LED 3030 |
| Surge Protection: | SPD 10KV |
Mechanical Specifications
| Minimum IK Rating: | IK10 |
| IP Protection Rating: | IP66 |
| Overall Dimensions | 340x373x185mm |
| Construction Material: | Toughened Alloy Construction |
| Adjustable Bracket: | 270 ̊ Adjustable Bracket |
| Recommended Ambient Temp: | -20 ̊C – 55 ̊C |
Main Features
- Newly design adjustable bracket included
- Configurable optical arrangements
- Glare Protection Accessories Available By request
- Optional Bird Protection Kit by Request
Photometric Information
| Typical Lumen Efficacy: | 140-150lm/W |
| CCT Colour Temperature: | 3000K/4000K/5700K/6500K |
| Colour Rendering (Ra): | >85Ra |
| Beam Angle/Viewing Angle: | 15 ̊ / 30 ̊ / 85 ̊ / 130 ̊x25 ̊ / 130 ̊x40 ̊ |
CONFIGURATION OPTIONS
MVF is a modular system available in power configurations from 230W-1350W. Mechanical cable protection and other mounting accessories available by request.
