SDL939 Square Surface Mount LED Downlight

Industralight SDL939 surface mounted LED downlights are square, compact and stylish fittings for locations that require a surface mounted downlight solution. The fittings have integral LED driver and are protected to IP65 making them suitable for all indoor and outdoor applications.

Electrical Parameters

Input Voltage: 100-265VAC
Power Consumption: 26W
LED Driver Classification: Integral Constant Current
Light Source Classification: XP-E LED

Mechanical Specifications

Minimum IK Rating: IK06
IP Protection Rating: IP65
Nominal Dimensions: 150 x 150 x 200mm(H)
Material/Construction: Extruded Alloy/Powdercoated
Recommended Ambient Temp: -20°C – 45°C

Configuration Options

  • 24VDC version available by special request
  • Non-standard colour finishes available by special request

Photometric Information

Typical Lumen Efficacy: 85-95lm/W
CCT Colour Temperatures: 3200K/4200K/6500K
Colour Rendering Index (CRI): >85
Beam Angle/Viewing Angle: 24° or 60°

Detailed photometric report and IES files available by request
